6.2 Configuration
The configuration defines which data content is exchanged in the cyclical data
communication. The following data is available for selection:
Input values:
Name Meaning Length
Gross gross measured value 1 or 2
words
Net net measured value (gross minus tare value) 1 or 2
words
Max contents of the maximum store 1 or 2
words
Min contents of the minimum store 1 or 2
words
Pk−Pk peak-to-peak, difference between max and min 1 or 2
words
Status1 status word with status of the limit switches and gen. error
bits
1 word
Status2 double status word with differentiated error flagging 2 words
Output values:
Name Meaning Length
Control word control word for triggering taring, zeroing, clearing the peak
value store, parameter set selection, etc.
1 word
GW1 level at which limit switch 1 responds 1 or 2
words
GW2 level at which limit switch 2 responds 1 or 2
words
GW3 level at which limit switch 3 responds 1 or 2
words
GW4 level at which limit switch 4 responds 1 or 2
words
The formats of the cyclically communicated data content are specified in detail
in chapter 6.3. The measured values care offered optionally as a 16-bit
integer, 32-bit integer or 32 bit float. The values are always scaled to physical
size with the number of decimal places of your choice. Information on whether
the 16 bit format or a 32 bit format is used and on the number of decimal
places is defined in the parameter assignment telegram.
Typical combinations are predefined in the GSD file. If you require other
combinations you can expand the GSD file accordingly using the following
specifications.
