141Connection
HBMQuantumX
6.11.27 PMW − Pulse width, Pulse duration, Period
duration (differential signals)
Supported by module: MX460
6
10
Transducer
9
4
f
1
(+)
Hsg.
Cable shield
Hsg. = Housing
6
1
123
1-wire EEPROM
(view from below)
1
5
6
10
11
15
2 Data
3 No function
1
Adjustable sensor supply: Pin 12: 5 V ... 24 V
Pin 11: 0 V
f
1
(−)
5
