HBX CPU-1000 - Mixing Options and Design Settings

HBX CPU-1000 HVAC Controller
Version 1.38
© HBX Control Systems Inc. 2012
Page 13
Description Options Range Factory
Default
Mixing
Options
• Boiler Options
• Injection Type
“Same as
last section”
PMI Valve
PMI Pump
Floating Action
Modulating
“Same as
last section”
PMIv
‘Valve’
Change
Design
• Design Boiler Temp
• Design System Temp
• Design System Temp 2*
• Design Room Temp
• Design Room Temp 2*
• Design Outside Temp
• Design Outside Temp 2*
• Min Boiler Temp
• Min System Temp
• Min System Temp 2*
• WWSD
• Default Designs
Staging*
• Default Designs
Mixing*
0ºF to 225ºF
0ºF to 225ºF
0ºF to 225ºF
-50ºF to 100ºF
-50ºF to 100ºF
-50ºF to 100ºF
-50ºF to 100ºF
40ºF to 200ºF
0ºF to 150ºF
0ºF to 150ºF
0ºF to 100ºF
o Lo Efficient
Building
o Mid Efficient
Building
o Hi Efficient
Building
o Lo Temp Radiant
o Hi Temp Radiant
o Fancoil
o Baseboard
o Lo Temp Radiator
o Hi Temp Radiator
190ºF
135ºF
135ºF
70ºF
70ºF
-10ºF
-10ºF
120ºF
75ºF
75ºF
75ºF
