HBX CPU-1000 - Setpoint and Setback Parameters; Graphing Parameters

HBX CPU-1000 HVAC Controller
Version 1.38
Page 14
Description Options Range Factory
Default
Setpoint
Options
• Setpoint 1
o Setpoint Temp
o Heating
o Cool Interlock
o Differential
o Lag Time
o Setpoint Demand
• Setpoint 2 and 3
Off/33ºF to 225ºF
Heat/Cool
Y/N
2ºF to 100ºF
0S to 600S
No/Lo/Hi Temp
As Above
OFF
Heating
N
2ºF
0S
Hi Temp
As Above
Setback
Options
• Use Setbacks
• Set Setbacks
o Start Time 1
o End Time 1
o Start Time 2
o End Time 2
o Start Time 3
o End Time 3
Y/N
0:00 – 24:00
0:00 – 24:00
0:00 – 24:00
0:00 – 24:00
0:00 – 24:00
0:00 – 24:00
N
Domestic
Setup
• Use DHW?
• DHW Valve
• DHW Priority
• Domestic Temp
• Differential
• DHW Interlock
• DHW Boiler Temp
Y/N
Valve/Pump
Y/N
32ºF to 225ºF
0ºF to 100ºF
Y/N
100ºF to 225ºF
N
Pump
N
100ºF
2ºF
N
150ºF
Graphing
• Boiler Graph
• System Graph
Target vs. Actual
Target vs. Actual
