3
SPEC
Accessories Main board (DB-M3602-02V01), 48 Keys IR controller, USB HDD BOX(customer option)
Board configuration 396MHz MIPS CPU, 128MB DDR400 RAM, Memory Clock 198Mhz, 4MB Serial
Flash, Single Tuner, DVB-S2 demodulator,
Power Supply Input 100V ~ 240V 50/60Hz
Power Consumption 30W Max / 1W Standby (it’s optional by customer’s board)
RS232 For FW Upgrading.
Standard Receiver
Standard
DVB-S2 Standard (ETSI EN 302 307)
Input Frequency Range 950MHz ~ 2150Mhz
Input Signal Level -25dBm ~ -65dBm
Demodulation QPSK, 8PSK, 16APSK
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
MPEG Profile Level MPEG2 SD, MPEG2 HD, H.264/AVC SD, H.264/AVC HD
LNB Power & Polarisation Vertical +13.5V, Horizontal 18V, Current: MAX 500ma,
Multi Satellite receiving 22K switcher, DiSEqC1.0, DiSEqC1.1, Unicable , DiSEqC1.2, USAL
Conditional Access system 1 Common Interface Slots ; 1 CA card reader Slots
A/V Output ports YPrPb, RCA with CVBS, SCART with CVBS, HDMI(HDCP), Left/Right analog audio
output(RCA), Digital audio output(SPDIF with coaxial or fiber)
Aspect Ratio Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box.
Audio Decoding MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2, AC3.
Audio Mode Stereo/MONO/Left/Right
DVR supporting DVR with USB HDD, Time shifting with USB HDD
USB2.0 High Speed HOST 1 USB2.0 Port, USB media player to playback the media in USB flash disk or USB
HDD or USB card reader with memory card or FW Upgrading.
File system FAT12, FAT16, FAT32, NTFS (only support first partition)
Media Supporting JPG, BMP, MP3, WMA
Ethernet Interface 10/100Mbit
Storage Temperature 0℃ to +50℃
