5
Rear Panel
Bottom Name Function
POWER Power swicth On/off
ETHERNET ETHERNET RJ-45(to ethernet)
RS-232 RS-232 Connect to a PC fro SW upgrade
HDMI HDMI port HDMI 1.3output
PVR USB port Connect to usb
CVBS CVBS Connect TV through RCA
AUDIOR/L AUDIOR/L Connect to audio R/L to TV/ Audio
LNB IN LNB IN Connect to satellite antenna
LNB OUT LNB OUT Connect to the other receiver
