Page
15
:;: :;:
~
Refer
to
Pictorial 10
for
the
following
steps.
( ) Prepare the
following
lengths
of
wire:
3-1/2"
green
6"
black
5"
white
4"
red
5"
white
5-1/2"
red
4"
black
( ) Connect a
3-1/2"
green
wire
from
lug 4
of
socket B F
(S-1)
tothe
lug
of
jack
BE
(NS).
( ) Remove
an
additional
1/4"
of
insulation
from
one
end
of
a
5"
white
wire. Connect this end
of
the wire
through lugs 2
(S-2)
and 5
(S-2)
to
lug 4
(S-1)
of
socket
BA
. Connect the other end
to
the lug
of
jack
BC
(NS) .
( ) Connect a
5"
white
wire
from
lug 1
of
socket BF (S-1)
to
the lug
of
jack
BC
(NS).
( ) Connect a
4"
black wire
from
lug 3
of
socket
BA
(S-1
)
to
the lug
of
jack
BB
(NS).
( ) Connect a
6"
black wire
from
lug 3
of
socket
BF
(S-1)
to
the lug
of
jack
BB
(NS).
Connect a
4"
red wire
from
lug 2
of
socket
BF
(S-1)
to
the lug
of
jack
BO
(NS).
Connect a
5-1/2"
red wire
from
lug 1
of
socket BA
(S-1)
to
the lug
of
jack
BO
(NS).
( ) Cut both
leads
of
a .005
IlF
disc capacitor
to
3/4".
Then connect this capacitor
from
the lug
of
jack
BC
(NS)
to
the
lug
of
jack
BO
(NS).
SUBPANEL
INSTALLATION
Refer
to
Pictorial
11
(fold-out
from
Page
17)
for
the
following
steps.
( )
Mount
the
meter on the
front
panel. Position the
meter
with
the positive (+) terminal
as
shown. Install
only
a lockwasher and
nut
at
BJ.
Use
the hardware
included
with
the meter.
( ) Place a
#6 spacer on meter mounting bolts BK, BL,
and BM.
( ) Locate the assembled subpanel and remove the control
nuts
from
controls
Sand
T.
( ) Install the assembled subpanel on the inside
of
the
front
panel .
( ) Install lockwashers and nuts
at
BK,
BL,
and BM.
Use
the hardware included
with
the meter.
Be
sure
pushbutton switches do
not
bind against the
front
panel.
If
necessary, reposition the
su
bpanel.
( ) Install
control
flat
washers and control nuts on
controls
Sand
T.
()
Remove and discard the shorting wire from between
the meter terminals.
