20 August 23, 20197074-801C
HEATILATOR ECO CHOICE CAB50
D. High Ash Fuel Content Maintenance
• Frequency: As needed
• By: Homeowner
Poor quality pellet fuel, or lack of maintenance, can create
conditions that make the re pot ll quickly with ashes
and clinkers.
This condition makes the appliance susceptible to
overlling the re pot with pellets which may result in
smoking, sooting and possible hopper res. Figure 20.1
shows an example where the re pot overlls, pellets
back up into the feed tube and ash has accumulated in
the rebox.
An inecient and non-economical method of burning of fuel
caused by poor quality pellet fuel is shown in Figure 20.2.
The correct ame size when good quality, premium pellet
fuel is burned is shown in Figure 20.3.
If the ash buildup exceeds the half way point in the repot
IMMEDIATE ATTENTION AND CLEANING IS REQUIRED.
E. Soot or Creosote Fire
Establish a routine for the fuel, wood burner and ring
technique. Check daily for creosote build-up until
experience shows how often you need to clean to be
safe. Be aware that the hotter the re the less creosote
is deposited, and weekly cleaning may be necessary in
the mild weather even though monthly cleaning may be
enough in the coldest months. Contact your local municipal
or provincial re authority for information on how to handle
a chimney re.
In the event of a soot or creosote re, close the rebox
door, exit the building immediately and contact the
proper re authorities.
DO NOT under any circumstances re-enter
the building.
Figure 20.3
Figure 20.1
Figure 20.2
Correct Flame Height
Yellow/White in Color
Incorrect Flame Height
Tall, Lazy Flame
Orange in Color
Pellets Back-up in Feed Tube
Ash build-up in Firebox
Firepot Overfills
WARNING
Fire Risk
• High ash fuels, or lack of maintenance,
can cause the repot to overll. Follow
proper shutdown procedure if ash buildup
exceeds halfway point in repot.
• Failure to do could result in smoking,
sooting and possible hopper res.
