Heatilator ECOCHOISE CAB50-C - Component Locations

30 August 23, 20197074-801C
HEATILATOR ECO CHOICE CAB50
Figure 30.2
Figure 30.1
Figure 30.3
Control Box
Junction Box
Red Call Light
Fuse
Convection
Blower
LOCATED BEHIND LEFT SIDE PANELS
LOCATED BEHIND RIGHT SIDE PANELS
Feed Motor
Vacuum Switch
Combustion Blower
Back of Appliance
Power Outlet
Terminal Block
Center 2 Screws for
Thermostat Wires
Heat Output Switch
Reset Button
B. Component Locations
