Heatilator ECOCHOISE CAB50-C - Table of Contents

3August 23, 2019 7074-801C
HEATILATOR ECO CHOICE CAB50
A. Sample of Serial Number / Safety Label ......... 2
B. Warranty Policy ............................ 4
C. Quick Start Guide .......................... 6
1 Listing and Code Approvals ..............7
A. Appliance Certication....................... 7
B. BTU & E󰀩ciency Specications ............... 7
C. Glass Specications ........................ 8
D. Electrical Rating (on high) .................... 8
E. Mobile Home Approved ...................... 8
F. Sleeping Room ............................ 8
G. California - Prop65 ......................... 8
2 Operating Instructions .......................9
A. Fire Safety ................................ 9
B. Non-Combustible Materials ................... 9
C. Combustible Materials....................... 9
D. Fuel Material and Fuel Storage................ 9
E. General Operating Information ............... 10
F. Before Your First Fire ....................... 10
G. Hopper Lid Latch and Hopper Switch .......... 11
H. Starting Your First Fire ..................... 11
I. Fire Characteristics......................... 12
J. Feed Rate Adjustment Instructions ............ 12
K. Ignition Cycles ............................ 12
L. Clear Space .............................. 13
M. Thermostat Operation...................... 13
N. Frequently Asked Questions ................. 14
3 Maintenance and Service .................15
A. Proper Shutdown Procedure ................. 15
B. Quick Reference Maintenance Chart .......... 15
C. General Maintenance ...................... 16
D. High Ash Fuel Content Maintenance........... 20
E. Soot or Creosote Fire ...................... 20
4 Troubleshooting Guide .....................21
5 Service Parts Replacement ..............24
A. Convection Blower Replacement ............. 24
B. Exhaust Blower Replacement ................ 25
C. Snap Disc Replacements ................... 25
D. Igniter Replacement ....................... 26
E. Ba󰀪e Removal & Replace................... 26
F. Glass Replacement ........................ 27
6 Reference Materials ..........................28
A. Component Functions ..................... 28
B. Component Locations ...................... 30
C. Maintenance and Service Log................ 31
D. Exploded Drawings ........................ 35
E. Service Parts ............................. 36
F. Accessories .............................. 38
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Heatilator Eco Choice is a registered trademark of Hearth & Home Technologies.
