Heatilator ECOCHOISE CAB50-C - Glass Replacement

27August 23, 2019 7074-801C
HEATILATOR ECO CHOICE CAB50
F. Glass Replacement
1. Open the door from the appliance by lifting door o󰀨 of
hinge pins and lay on a at surface face down.
2. Using a Phillips Head screw driver, remove the 4
brackets and set aside (Figure 27.1).
3. Remove old glass and replace with the new glass.
4. Re-install the brackets using the same screws.
Glass Assembly
1
2
3
4
Remove the 4
brackets outlined
in the diagram
Figure 27.1
• Glass is 5mm thick high temperature
heat-resistant ceramic glass.
• DO NOT REPLACE with any other
material.
• Alternate material may shatter and
cause injury.
WARNING
