37August 23, 2019 7074-801C
Service Parts
CAB50-C
Beginning Manufacturing Date: Mar 2019
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and
Home Technologies does not sell directly to consumers. Provide model number and serial number when
requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
8 Firepot Assembly SRV7034-072B Y
Gasket, Firepot SRV7034-190 Y
9 Heating Element Assembly 18” (Loop Igniter)
Pkg of 1 SRV7000-462 Y
Pkg of 10 SRV7000-462/10 Y
10 Firepot Bottom SRV7034-153 Y
11 Spring Pkg of 4 7000-513/4 Y
12 Hitch Pin Clip 3/32 Pkg of 10 7000-374/10 Y
13 Rail, Auto-Clean SRV7034-152 Y
14 Pull Rod SRV7074-141 Y
15 Ash Pan Assembly SRV7058-013
Heatilator Logo Pkg of 10 4021-049/10
16 Latch Backing Plate SRV7058-155
17 Exhasut Combustion Blower, 70 CFM SRV7000-602 Y
18 Gasket, Exhaust Combustion Blower SRV240-0812 Y
Gasket, Combustion Blower, Round 812-4710 Y
19 Casting, Exhaust Transition 180-0190
20 Convection Blower, 220 CFM SRV7000-108 Y
21 Wire Harness SRV7058-150 Y
22 Blower Retainer SRV7058-148
23 Control Board 3 Speed Eco-Choice SRV7058-188 Y
24 Snap Disc F110F-20 ( #1 ) SRV230-1220 Y
25 Snap Disc L175F Manual Reset ( #2 ) SRV230-1960 Y
26 Feed Assembly SRV7058-007 Y
Feed Bearing SRV7000-598 Y
Feed Motor 812-4421 Y
Feed Spring Assembly (Only) SRV7001-046 Y
Gasket, Feed Motor SRV7034-144
27 Snap Disc L250F Manual Reset ( #3 ) SRV230-1290 Y
28 Side Curtain Qty 2 req SRV7074-124
29 Vacuum Switch SRV7000-531 Y
Additional Service Parts on following page.
Snap discs
24
25
27
F110F-20
L175F Manual Reset
L250F Manual Reset
To Next Page
