01-02 5 28466 Rev H
NOVUS B-VENT INSTALLATION INSTRUCTIONS
1. APPLIANCE LOCATIONS AND SPACE
REQUIREMENTS
Figure 1 illustrates a variety of ways the appliance
may be located in a room. The NOVUS Series may be
installed directly on the floor or raised on a hearth.
These appliances are certified for installation in a
bedroom, bed/sitting rooms or bathrooms in the U.S.
and Canada, provided that the bedroom or bathroom
has a volume of at least 540 cubic feet.
Common venting of this gas appliance with other gas
appliances is not allowed in multifamily dwellings.
2. CLEARANCES
Figure 2 shows all clearances that must be
maintained around the appliance.
Figure 1
Appliance Locations
Figure 3 shows a typical framing of this appliance using
combustible materials. All required clearances to
combustibles must be adhered to.
CAUTION
Wear gloves and safety glasses for protection.
C. FRAMING
Figure 2
Appliance Clearances to Combustible Materials
We strongly recommend that you DO NOT install
B-Vent Gas Appliances in strong negative air
locations, such as a basement or a public facility.
Living rooms with cathedral ceilings could be
susceptible to a negative air situation, but such
installations can be overcome through raising
the termination, depending on specific
installations. This appliance uses room air for
normal operation and could have problems
establishing a positive draft in a negative air
location. In lieu, we recommend a direct vent
appliance.
Figure 3 - Framing
LEDOMABC
03CBNG43
1
/
4
"84
1
2/
"53
7
/
8
"
33CBNG63
1
/
4
"15
1
/
4
"83
7
/
8
"
63CBNG83
3
/
8
"45
1
/
4
"14
7
/
8
"
LEDOMA
03CBNG53
7
/
8
"
33CBNG83
7
/
8
"
63CBNG14
7
/
8
"
