Heatmiser DT - Page 9

NC
L
N
COM
NO
DT
FUSE AT 3 AMPS
CHANGE OVER
L
N
VOLT FREE
TO BOILER
CONTROL
CIRCUIT
Set-point range: 5-35 °C (Room)
Switch Current Rating: <3A
N
LOAD
L
FUSE AT 16 AMPS
DT
DT
HIGH POWER
L
N
e.g.
Electric Underfloor heating
Set-point range: 5-35 °C (Room)
Switch Current Rating: <16A
Heatmiser DT
Heatmiser DT
15 16
