20 / 28
CAUTION!A
Pull out the power plug immediately if the cable is damaged, badly twisted or has
been completely cut through.
ADJUSTMENT OF THE TELESCOPIC TUBE (FIG. 8)
C Disconnect your gardening tool from the power supply.
Loosen the locking knob for length adjustment
g
completely.
Push the telescopic tube to the desired length .
Finally tighten the locking knob firmly.
ADJUSTMENT OF ENGINE HEAD (FIG. 9)
Press the angle adjustment, and adjust the engine head until it snaps into the desired position.
CAUTION!A
After adjustment make sure that the angle adjustment buttons have returned to
their initial positions. Otherwise the tool cannot start.
WORKING WITH THE HEDGE
During cutting work, ensure that no contact is made with hard objects, e.g. such as wire fencing
or main plant stems. This may result in damage to the cutter bar.
CAUTION!A
WARNING! Switch off the equipment immediately in the event that the blades are
blocked by solid objects, pull out the power plug then remove the object.
Always work away from the mains power outlet. Set the cutting direction before starting work. Ensure
that the power cable is kept well away from the working area. The belt clip included in the package for
hooking up the extension cable will help you. Never lay the cable over the hedge, where it could easily
be caught up in the trimmer blades. Avoid overstraining the equipment during work.
CAUTION!A
WARNING! Pull out the power plug immediately if the cable is damaged, badly
twisted or has been completely cut through.
CUTTING TECHNIQUES
• Cut thick branches beforehand using a sawing or branch clippers.
• The double-sided cutter bar enables cutting in both directions or, with a swinging action,
from one side to the other.
HECHT_675_manual_2019_ EN.indd 20 11.03.2019 8:03:24
