• Parts of the packaging (plastic bags, paper clips, etc.) do not leave within reach of children,
could be a possible source of danger. There is a danger of swallowing or suffocating!
• If you notice transport damage or while unpacking, notify your supplier immediately. Do not
operate the product!
• We recommend save the package for future use. The packaging materials must still be
recycled or disposed of in compliance with the relevant legislation. Sort different parts of
the packaging according to material and hand it to the appropriate collection sites. For
further information contact your local administration.
C Fasteners can become loose during transport in the packaging.
PACKAGE CONTENTS
Unpack the machine carefully from the packaging and check if the parts are complete.
• Motor housing with tines and frame tubing.
• Right-hand fork with dead-man lever and permanently fixed mains cable.
• Left-hand fork grip
• Plastic cross-plate with cable guide.
• Assembly tools, cable clips and belt clip.
• User manual.
• Standard accessories are subject to change without notice.
• This product requires assembly. The product must be assembled correctly before use.
INSTRUCTIONS FOR ASSEMBLY
CAUTION! A
Pull out the mains plug before any work on the instrument.
Be careful when mounting it to the capture cable to not demage and to have
sufficient clearance.
WARNING! B
Do not attempt to move the machine to run unless fully assembled!
1. Wheels onto the axle, fasten with screws and washers
(PIC. 2-1)
. Push the lid into the wheel
and make sure that they are firmly established.
2. Handle- Insert the middle part of the bottom piece, align and tighten the screws
(PIC. 2-2)
.
3. The middle part connect with mounted handle
(PIC. 2-3)
. Screw them together with
the supplied screws and wing nuts. Handle touch with the upper part of the handle screw
(PIC. 2-4)
.
OPERATION
C Before switching the tool on, make sure that the tool is not touching any other
objects and hold it firmly in both hands.
