Hectronic Citea - Communication Tests; Function Tests

Installation & Commissioning
42
Hectronic GmbH | Allmendstrasse 15 | D-79848 Bonndorf | Tel. +49 7703 9388-0 | Fax +49 7703 9388-60 | mail@hectronic.com
Managing Directors: Stefan Forster, Eckhard Fechtig, Frank Gampp | District Court Freiburg, HRB 621170 | VAT ID No.: DE170986709
To do...
Done
Run service routine 5.1.3 "Print software" and check the Hecapp and HecSys version. If the unit does
not have the correct firmware, perform an update (

Maintenance Manual Citea)

Set the date and time with Serviceroutine 2.0.

Import all necessary files (configuration, fares, masks, ticket profile) via a USB stick and service routine
13 "CityLine offline".

3.3.1. Function Tests
To do...
Done
Check that the configuration and tariffs are correct by making payments with coins and/or banknotes,
cards, etc.

Check if the coin return works (cancel payment).

Check whether the indication in the display is correct.

Check the information on the ticket and the layout of the ticket.

Check the functionality of ALL buttons.

If possible, carry out a coin cassette change. Check whether a statistics slip is printed. Print a statistics
slip via service routine 1.0.0 and check whether all values have been reset.

Check the special functions if the unit has them.

3.3.2. Communication Tests
To do...
Done
Check that the modem is correctly connected to the FUMO board (power supply and data line).

Check that the FUMO board is correctly plugged onto the AC-ARM9 board.

Check that the antenna is connected correctly.

Check that the SIM card is inserted correctly. The SIM card must be enabled for 2G/4G connections.

Print a Comms Config document via service routine 5.1.2 and check that the settings previously
configured in CityLine have been transferred correctly.

Check whether the machine is sending status messages correctly. To do this, it is best to open and
close the door of the electronics compartment a few times; the status messages are displayed in
CityLine.

