29
441 01 2121 01
Figure 35 − Upflow Application − Vent Elbow Up
SEE NOTES: 1,2,4,7,8,9
on the page following
these figures
A03208
Figure 36 − Upflow Application − Vent Elbow Right
SEE NOTES: 1,2,3,4,7,8,9
on the pages following
these figures
A03209
Figure 37 − Downflow Application − Vent Elbow Up then
Left
SEE NOTES:1,2,3,4,5,7,8,9
on the page following
these figures
A03210
Figure 38 − Downflow Application − Vent Elbow Up
SEE NOTES: 1,2,4,5,7,8,9
on the page following
these figures
A03211
