30
441 01 2121 01
Figure 39 − Downflow Application − Vent Elbow Left then
Up
SEE NOTES: 1,2,4,5,6,7,8,9,10
on the page following these figures
A03207
Figure 40 − Downflow Application − Vent Elbow Up then
Right
SEE NOTES:1,2,3,4,5,7,8,9
on the page following
these figures.
A03212
Figure 41 − Horizontal Left Application − Vent Elbow Left
SEE NOTES: 1,2,4,7,8,9 on the page
following these figures
A03213
Figure 42 − Horizontal Left Application − Vent Elbow
Right then Up
SEE NOTES: 1,2,4,5,7,8,9 on the page
following these figures
A03214
Figure 43 − Horizontal Right Application − Vent Elbow
Right
SEE NOTES: 1,2,4,7,8,9 on the page
following these figures
A03218
