Heiniger ICON - 1 Proper Use; Overall View; Controls

Instruction manual ICON 3
Pos Description Total
1 Barrel ICON 1x
2 Centre post 1x
3 Locknut 1x
4 Comb screw 2x
5 Crankshaft 1x
6 Ball 1x
7 Safety screw 1x
8 Oil hole cap 1x
9 Tension nut bushing screw 1x
10 Retaining ring 1x
11 Tension pin 1x
12 Tension sleeve upper 1x
13 Tension nut 1x
14 Distance washer 1x
15 Ball bearing 1x
16 Spring washer 1x
17 Gliding bush 1x
18 Retaining ring JV 27 x 1.2 Typ J 1x
19 Seal 1x
20 Back joint cover 1x
1 Proper Use
1.1 Overall View / Controls
Component Names
Illustr. 0
Pos Description Total
21 Back joint cap 2x
22 Back joint spring 1x
23 Inner back joint 1x
24 Outer back joint 1x
25 Ball bearing 2x
26 Cog Z14 2x
27 Drive shaft ICON PIN-Drive (1x)
28 Tapered pin Ø3 x 12 mm 1x
29 Drive shaft ICON WORM-drive 1x
30 Chicken feet retaining spring 1x
31 Pan-head screw M4 x 5 1x
32 Centre post cup 1x
33 Fork body 1x
34 Tension pin retaining spring 1x
35 Tension pin cup 1x
36 Chicken feet L+R (pair) 1x
37 Fork body assembly complete (1x)
38 Ferrule Ø22 x 180 mm solid-drive (1x)
38 Ferrule Ø22 x 160 mm flex-drive (1x)
