Instruction manual ICON 11
4.4 Storing
Only store the shearing handpiece in a dry place. Do not connect it to a shearing drive if you
suspect any liquid has got into it. There is then the risk of a corroded and therefore seized drive
mechanism which, if you try to run the handpiece, can cause injury.
Make it a habit to store the machine between use, store it well-cleaned, oiled and with tension
slackened off, in a clean, dry place, out of the reach of children.
5 Maintenance & Repairs
This product has been developed and assembled using the best individual components
available. It is designed to give longevity and high performance. If spare parts are used during
the life of this product, please ensure that they are genuine Heiniger parts. Failure to use
genuine Heiniger spares may reduce the performance of this precision engineered product and
will void any warranty claim.
5.1 Introduction
Always contact an authorised service centre if you are unsure how to rectify the problem and in
the event of malfunctions not contained in these instructions
Details of authorised service centres are to be found at the end in the „7 Contact Addresses“
section.
5.2 Maintenance
It is impossible for us to say how often you should replace parts, as wear factors vary from
country to country and shed to shed, however, the components are manufactured from the
highest quality metals that will enhance the life expectancy of your handpiece.
5.3 Repair Kits
Three repair kits are available. It is advisable to fit complete repair kits and not replace indivi-
dual parts when carrying out a service, this will ensure the smooth and true running of your
shearing handpiece.
Repair kits consists of the following parts:
Illustr. 23
•tensionsleeve
•tensionpin
• tensionpincup
• tensionpinretaining
spring
• centrepost
• centrepostcup
•tensionsleeve
•tensionpin
•tensionpincup
•tensionpinretaining
spring
•centrepost
•centrepostcup
•centrepostlocknut
•2xcogs
•ball
•Frontbearing
•Backhalfjointbearing
•seal
•wavewasher
•circlip
•distancewasher
Short Replacement Kit Bearing Replacement KitLong Replacement Kit
