Replaceforkbody.
Replacebearing.
Checktheballraceinthefork
issmooth.
Checkthefrontbearingfor
wear.
Replacecapsandbackjoint
spring.
Checkyouhavenomovement
betweenthebackhalfjoints.
Replacecogs.Checkyourcogsareingood
condition.
Replacethebushfirst,ifitisstill
sloppyreplacetheinnerback
halfjoint(alwaysreplacethe
seal).
Checktheinnerbackhalfjoint
isagoodfitinsidethebush
withnosidewaysmovement.
Replaceifworm.Checkthebearingsintheinner
andouterbackhalfjoints.
Checktheforkisnothittingthe
crankshaftheadbecausethe
postisnotcorrectlyset.
Resetpost.
Checktheferruleisnotsloppy
insidetheshorttube.
Changetheshorttubeandthe
ferrule.
Hasyourhandpiecelockedup
andbentthecrankshaft?
Replacethecrankshaft.
Vibrationfrombackend.
MALFUNCTION RECTIFICATIONCAUSE
