Heiniger ICON - Page 35

18 Instruction manual ICON
• Tofitthefrontbearing,placethecrankheadonthepieceofwood(Illustration21)withthe
pin facing down over the edge, place the distance washer (the flat one) over the crankshaft
and then the remaining (biggest) bearing. Using tool no. B with the thread to the top hit the
tool until the bearing is positioned against the seat behind the crank head. Take care that
the distance washer does not get caught between the bearing and the seat behind the crank
head, the distance washer should always be free moving
• Cleanthebarrelthoroughly(nowisagoodtimetofitarugifrequired).
• Ensuringallbearingsareseatedproperlybeforebeginningtoreassemble.
• Placethemouthofthebarrelonthepieceofwood(Illustration15)andlowerthecrankshaft
with bearing fitted into the barrel, slide small end of tool no. D into the barrel and gently tap
the tool until it rests against the end of the barrel.
• Placethenewwavewasheroverthecrankshaftandloweritontobearing.
• Cleanthebushandcoatitandtheinsideofthebarrelwithlightoil,slidethebushdownon
top of the wave washer.
• FitNEW circlip (do not over compress the circlip when fitting because it will rub on the
inner back half joint and make the back end tight) inside the barrel, then using the small end
of tool no. D against the circlip, tap the circlip into its seat. Make sure the circlip is seated
properly in the groove.
• Reassemblethetwobackhalfjointswithnewgreaseinthebackjointcaps.
• PlaceaNEW seal over the inner back half joint (see back joint removal and replacement and
Illustration 10) and oil liberally.
• Coatinnerbackhalfjointandinsideofbarrelwithoilandslideinnerbackhalfjointintothe
barrel and screw the cog onto the end of the crankshaft.
• Reassemblethewormorpindriveandcog.
• Refittheforkmakingsuretheflatsideoftheballisfacingthecrankshaft(Illustration22).
Fitting Pin Drive Pin
The pin drive pin is tapered, identify the small end of the broken pin and tap this small end of
the pin with a punch to remove it. Tap in the new pin gently, don’t hit it hard or you will crack
the end of the shaft. Place the big end of your pin on an anvil or something solid and round
off (or burr over) the small end of the pin ensuring it is a good fit into the shaft, finish this job
by filing the small end flush with the shaft. Make sure the big end does not protrude out past
the outer rim of the drive coupling, if it does this will rub on the tube and run hot, file off the
excess.
Adjust Centrepost using a Post Guide
The post has a notch in the bottom around from the screwdriver slot (Illustration 16). Use this
notch as a setting mark and once you have the handpiece cutting well remember or write
down where this mark is, this will enable you to reset the post to the original position should
the need arise.
• Setafreshlygroundcombandcutterthatis3mmthick.
• Applynormaltensiontocutter.
• Movethecutteruntiltheballisatthebottomoftheforkandthecutterisinthemiddleof
the comb.
• Loosenthecentrepostlocknut.
• InsertthePostGuide(Illustration17)intheholeandsitthefirstledgeontheforkatthefront
of the ball race.
Illustr. 21
Illustr. 15
Illustr. 10
Illustr. 22
Illustr. 16
