14 | Assembly position
6. Assembly
position
CAUTION
Selecting the correct assembly
position in the room is decisive for
the functioning of the smoke alarm.
f Select an assembly position
in which smoke can reach
the smoke alarm without any
obstructions and thus enables an
early detection.
f The standard case and special
cases must be observed.
Genius Plus X:
If radio smoke alarms are used,
the chapter
“Project planning” in the
“Standard X radio module”
operating manual is also to be
observed.
6.1 Standard case
The following conditions apply to
the correct assembly position:
 On the ceiling
 As close to the centre of the
room as possible, but at least
0.5m away from walls, beams or
furniture (e.g. lamps).
 Maximum room height: 6 m
 Monitored area per smoke alarm:
max. 60 m²
i
max . 6m
at least 0.5 m at least 0.5 m
max. 60 m
2
