18 | Assembly
7. Assembly
The following options are available
for the assembly of the base:
Screw/dowel assembly with
1screw: see 7.1
Screw/dowel assembly with
2screws: see 7.2
Assembly with an adhesive pad:
see 7.3
For a secure and permanent
connection, Hekatron recommends
the screw/dowel assembly.
The fastening material for a
1-hole assembly is included in
the scope of delivery. If other
screws are to be used, the
screw heads must not reach
into the base by more than
5mm. We recommend using
3.5 x 25mm oval-head screws.
CAUTION:
Depending on the selected assembly
method, lines may be damaged.
f Select the assembly position in
away that it can be ensured that
no electric lines or other supply
lines (e.g. water) can be damaged
during drilling.
i
