JS07N·JS07·JS08·JS12·JS14
13
Controls
Update program
Note: Updating the program will restore all
system settings debugged by the original ma-
chine owner/user/ HELI to the original settings
set by the control system manufacturer.
Therefore, it is prohibited to update the pro-
gram without the authorization of HEL. If you
need to update the program, please contact
HEL after-sales personnel.
Check program version
When the machine is powered on, the screen
will display the current program version in the
first 2s of startup. If “06 E501_standard ” is
displayed, the program version is correct.
Set Speed
In the “1.Set Speed” menu, the Max Fast
Speed, Max Low Speed, Max Raised Speed,
Max Lift Speed, Max Steer Speed and Steer
Boost can be set.
Set option
 In the “2.Set Option” menu, the Machine
Type, Load Sensor Mode and Pressure
Sensor Mode can be selected.
 In the “2.Set Option” menu, the Drain
Alarm Time, Drain Shut Time can be set.
 In the “2.Set Option” menu, the Pothole
Guard, Descent Delay, Motion Alarm, Load
Sensing, High Torque, Limit Drive, Foot
Pedal, Anti-collision and BMS Function can
be switched on or off. However, the Pot-
hole Guard, Load Sensing and Motion
Alarm functions are switched on by default.
Even if these functions are turned off man-
ually, they will return to the default ON
state when the machine is powered on
again.
Calibrate joystick
Ensure the joystick is in neutral position
before poweron.
Calibrate weight and height
NOTICE
• The height calibration will be carried
out automatically while the weight cali-
bration is performed.
• Weight calibration includes no-load
calibration and full-load calibration.
Please complete the calibration with the
ECU panel within one cycle as per the
following procedures.
• No-load calibration (& height calibration)
1. Lower the platform to the stowed posi-
tion, and ensure that the space above the
platform allows the platform to be safely
lifted to the maximum height.
2. Make sure no heavy objects are placed
on the platform.
3. After entering the ECU menu selection
mode, select and enter Calibration inter-
face, and press the Enter key for confir-
mation.
4. When the screen displays “Execute No
Load Calibration?”, press the Enter key
for 5s to start automatic no-load calibra-
tion.
5. The platform will rise and descend for
three times automatically: rise to the
highest position and descend to the
stowed position (the first, second and
06 E501_standard
3. Calibration
Execute No Load Cal-
ibration?
