Controls
third ascending and descending move-
ments are for height calibration, static
calibration and dynamic calibration re-
spectively).
6. When the screen displays “No Load Cali-
bration Complete!”, the no-load calibra-
tion (& height calibration) is successfully
done.
7. Return to the Calibration interface
through the Return key.
• Full-load calibration
1. Place heavy objects with the same
weight as the rated load of the machine
on the platform.
2. Select and enter “Execute Full Load Cali-
bration? “interface, and press the Enter
key for 5s to start automatic full-load cali-
bration.
3. The platform will rise and descend for
three times automatically: rise to the
highest position and descend to the
stowed position (the first, second and
third ascending and descending move-
ments are for height calibration, static
calibration and dynamic calibration re-
spectively).
4. When the screen displays “Full Load Cal-
ibration Complete!”, the full-load calibra-
tion is successfully done.
5. Return to the main interface through the
Return key, and power off the machine as
needed.
Brake release (for electrically-driven mod-
els only)
1. Choke the wheels of the machine to pre-
vent it from rolling.
2. Make sure there are no obstacles on the
passage.
3. Lower the platform to the stowed posi-
tion.
4. After entering the ECU menu selection
mode, select and enter “Brake Release”
interface, and press the Enter key for 5s.
5. When the screen displays “Brake is Re-
leased” and the horn sounds, the brake
release is successfully done.
6. Return to the main interface through the
Return key, and power off the machine as
needed. The setting will reset automati-
cally after power-off and restart.
Set OL Descent Height
1. Ensure that the space above the platform
allows the platform to be safely lifted to
the maximum height and the machine is
horizontally positioned.
2. After entering the ECU menu selection
mode, select and enter “OL Descent
Height” interface.
3. Raise the platform to a certain height (the
desired OL descent height) with the
ground controller.
After pressing the Enter key for 5s,
the system will return to the previous
interface. Then the OL descent height
No Load Calibration
Complete!
Execute Full Load
Calibration?
Full Load Calibration
Complete!
Brake Release
Brake Released
OL Descent Height
