JS07N·JS07·JS08·JS12·JS14
17
Controls
Code
Problem
Action
Limit
Solution
42
Platform Left
Button ON
Diagnostic
Message
Only
Platform Left Turn Switch ON at power-up Message:
Ensure that nothing is holding the Joystick Toggle
Switches down. If OK, consider replacing the Joystick or
PCU.
43
Platform Right
Button ON
Diagnostic
Message
Only
Platform Right Turn Switch ON at power-up Message:
Ensure that nothing
is holding the Joystick Toggle Switches down. If OK,
consider replacing the Joystick or PCU.
46
Platform Ena-
ble Button ON
Disable
Platform
Control
Platform Joystick Enable Switch ON at power-up Fault:
Ensure that
nothing is holding the Enable switch closed. Also check
the neutral zone parameters. If OK, consider replacing
the Joystick or PCU.
47
Joystick Not
In Neutral
Lift Slow to
Drive
Speed
Platform Joystick not in neutral at power-up Message:
Make sure that the Joystick is in the neutral (upright) po-
sition. Check the neutral zone parameter setting in the
LabView Programmer. If it’s OK, consider replacing the
Joystick or the PCU.
52
Forward Coil
Fault
Disable
Lifting and
Driving
Forward Coil Fault: Check the connections to the Coil’s
terminals and make sure they are tight. If so, check the
coil itself to see if it is open or shorted.
53
Reverse Coil
Fault
Disable
Lifting and
Driving
Reverse Coil Fault: Check the connections to the Coil’s
terminals and make sure they are tight. If so, check the
coil itself to see if it is open or shorted.
54
Lift Up Coil
Fault
Disable
Lifting and
Driving
Lift Up Coil Fault: Check the connections to the Coil’s
terminals and make sure they are tight. If so, check the
coil itself to see if it is open or shorted.
55
Lift Down Coil
fault
Disable
Lifting and
Driving
Lift Down Coil Fault: Check the connections to the Coil’s
terminals and make sure they are tight. If so, check the
coil itself to see if it is open or shorted.
56
Right Turn
Coil Fault
Disable
Lifting and
Driving
Right Turn Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
57
Left Turn Coil
Fault
Disable
Lifting and
Driving
Left Turn Coil Fault: Check the connections to the Coil’s
terminals and make sure they are tight. If so, check the
coil itself to see if it is open or shorted.
58
General
Brake Coil
Fault
Disable
Lifting and
Driving
General Brake Coil Fault: Check the connections to the
Coil’s terminals and make sure they are tight. If so,
check the coil itself to see if it is open or shorted.
68
Low Voltage
Fault
Disable All
Motion
Low Voltage Fault: Check battery voltage and charge if
necessary. Check the battery connections and tight or
clean. Check the voltage to the ECU and PCU.
80
Over 80%
Load Warning
Warning
Only
Over 80% Load Warning: Platform is getting close to its
limit of weight. Consider not adding more load.。
82
Left Brake
Coil Fault
Disable
Lifting and
Driving
Brake coil error of left travel motor: check the connec-
tion of brake coil and confirm there is no problem. If
there is no problem, check whether the coil itself is short
circuited or open circuited.
83
Left Brake
Coil Fault
Disable
Lifting and
Driving
Brake coil error of right travel motor: check the connec-
tion of brake coil and confirm there is no problem. If
there is no problem, check whether the coil itself is short
circuited or open circuited.
