HELI JS07N - Page 29

JS07N·JS07·JS08·JS12·JS14
27
Operating Instruction
Repair any function that operates when either
red Emergency Stop button is pushed in.
Emergency Lowering
1. Pull the emergency lowering knob to lower
the platform.
Operation from Ground
1. Be sure the battery pack is connected be-
fore operating the machine.
2. Turn the key switch to ground control.
3. Pull out both ground and platform red
Emergency Stop buttons to the on posi-
tion.
To Position Platform
1. At the ground control panel, press and
hold the lift toggle switch.
Drive and steer functions are not available
from the ground controls.
Operation from Platform
1. Turn the key switch to platform control.
2. Pull out both ground and platform red
Emergency Stop buttons to the on posi-
tion.
3. Be sure the battery pack is connected be-
fore operating the machine.
To Position Platform
1. Press the lift function button.
2. Press and hold the function enable switch
on the control handle.
3. Move the control handle according to the
markings on the control panel.
To steer
1. Press the drive function button.
2. Press and hold the unction enable switch
on the control handle.
3. Turn the steer wheels with the thumb
rocker switch located on the top of the
control handle.
To drive
1. Press the drive function button.
2. Press and hold the function enable switch
on the control handle.
3. Increase speed: Slowly move the control
handle off center.
Decrease speed: Slowly move the control
handle toward center.
Stop: Return the control handle to center or
release the function enable switch.
Use the direction arrows on the platform con-
trols and on the platform to identify the direc-
tion the machine will travel.
Machine travel speed is restricted when the
platform is raised.
Battery condition will affect machine perfor-
mance.
Machine drive speed and function speed will
drop when the battery level indicator is flashing.
Decrease drive speed
The drive controls can operate in two different
drive speed modes while in the stowed position.
When the drive speed button light is on, slow
drive speed mode is active. When the drive
speed button light is off, fast drive speed mode
is active. Press the drive speed button to select
the desired drive speed.
Note: When the platform is elevated, the drive
speed button light is always on, indicating ele-
vated drive speed.
Drive on a slope
Determine the slope and side slope ratings for
the machine and determine the slope grade.
Slope at Stowed
Position
Side Slope at
Stowed Position
