HELIX Compressor 9600 - Specifications; Dimensions; Figure 1-2: 9600 Compressor Dimensions

9600 Compressor Description
1-4 P/N 8040540
C
HELIX TECHNOLOGY CORPORATION
-
TI C
RY
OG
EN
ICS
Specifications
Dimensions
The dimensions of the Compressor are shown in Figure 1-2.
Figure 1-2: 9600 Compressor Dimensions
CAUTION
Do not place a weight greater than 75 lbs. (34Kg) on top of the
Compressor.
19.52 IN.
(496 MM)
21.50 IN.
(546 MM)
1.28
(32MM)
23.36 IN.
(593 MM)
3.18 IN.
(81 MM)
14.4 IN.
(366 MM)
