9600 Compressor Installation, Operation, and Maintenance

P/N 8040540 1-7

HELIX TECHNOLOGY CORPORATION

TI C

ICS

General

The information in Table 1-4 provides general Compressor operating

specifications.

NOTE: The 9600 Compressor is designed for continuous operation and

should remain ON when the cryopumps are in a regeneration cycle.

Table 1-4: General Compressor Operating Specifications

Specification Values

Part Numbers

Input Power Cable

(Customer Supplied)

600 VAC

10 Gauge, 3 conductor wire with ground

Must conform to local electrical codes

Nominal Helium Pressure Refer to Table 4-1

Ambient Operating

Temperature Range

50 - 100º F (10 - 38º C)

Interface

Gas Supply Connector

Gas Return Connector

Remote Control Receptacle

Cryopump Power Receptacles: mates with the

CTI-CRYOGENICS supplied cryopump power cable for

single pump use.

Mates with remote junction box power cable for multiple

cryopump use.

1/2 in. Aeroquip self-sealing coupling

24VAC, 2.7A inductive mates with P5 connector P/N

MS3106A*

Adsorber Service Schedule 3 Years

* Supplied by CTI-CRYOGENICS
