9600 Compressor Description
1-8 P/N 8040540
C
HELIX TECHNOLOGY CORPORATION
-
TI C
RY
OG
EN
ICS
Component Description
The components of the 9600 Compressor that are accessible from the rear
panel are shown in Figure 1-4 and described in the following paragraphs.
Figure 1-4: 9600 Compressor Rear View Component Locations
CONTROL CIRCUIT
BREAKER
SYSTEM CIRCUIT
BREAKER
POWER
INLET
GAS CHARGE
FLARED FITTING
HELIUM
PRESSURE
GAUGE
CRYOPUMP
ELECTRICAL
OUTLET
SUPPLY GAS
COUPLING
RETURN GAS
COUPLING
COOLING
WATER
OUT
COMPRESSOR REMOTE
CONNECTOR
REAR PANEL
GAS CHARGE
CONTROL
VA L V E
COOLING
WATER
IN
POWER ON
INDICATOR
SERVICE I/O
CONNECTOR
CRYOPUMP
POWER PHASE
SWITCH
