HELIX M SIX - Examples of Speaker Configurations; 6-Channel Application with 2 x2 Ohm Subwoofer; 5-Channel Application with 1 x4 Ohm Subwoofer

16
Examples of speaker congurations
6-channel application with 2 x 2 Ohms subwoofer
Component system + coaxial system + subwoofer
Channel A/B
Highpass lter
Kanal E/F
Bandpass / Summed
Channel C/D
Highpass lter
Left Right
Left Right
Front
Rear
VC 1
VC 2
VC = Voice coil
50 - 100 Hz
HPF
HPF
50 - 100 Hz
LPF
Lowpass lter
50 - 100 Hz
5-channel application with 1 x 4 Ohms subwoofer
Component system + coaxial system + subwoofer
Left Right
Left Right
Front
Rear
Subwoofer
Subwoofer (E/F bridged)
Summed
Channel A/B
Highpass lter
Channel E/F
Bandpass / Summed
Channel C/D
Highpass lter
50 - 100 Hz
HPF
HPF
50 - 100 Hz
LPF
Lowpass lter
50 - 100 Hz
Summed
Subsonic /
highpass lter
ca. 20 Hz
Subsonic /
highpass lter
ca. 20 Hz
