Hellenbrand WM1-16M - Physical & Capacity Specification; Job Specification Sheet

3
JOB SPECIFICATION SHEET
*WATER TEST
_______ Hardness CaCo
3
(gpg) ______ Other______________________
_______ Iron (ppm) ______ Other______________________
_______ pH ______ Other______________________
*SIZING INFORMATION
All Water is Softened Except:
_______ Rear Hose Bib _______ Front Hose Bib _______ Kitchen Cold _______ Toilets
_______ Other _________________________________________________________________________________________
The average family uses 70 gallons per person daily for all water uses in the home, about 50 gallons per person daily if hard
water can be supplied to the toilets, and about 30 gallons per person daily for hot water only.
_________ Daily Water Usage (Gallons/Person)
x _________ Family Size
= _________ Total Gallons Per Day
x _________ Grains Per Gallon of Hardness
= _________ Total Grains Per Day
*REGENERATION SETTINGS
Time Clock: Automatic Regeneration Every _______ Days Using _______ Lbs./Salt
Meter Demand: Automatic Regeneration Every _______ Gallons Using _______ Lbs./Salt
Meter Setting _______ People/_______ Hardness
*INSTALLATION DATE __________________________________ MANUFACTURE DATE__________________________________
SERIAL NUMBER ______________________________________________________________________________________________
NOTES _______________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
*To be lled in by dealer.
CAPACITY & PHYSICAL SPECIFICATIONS
1. These conditioners are designed for hardness removal.
2. Limit of 2ppm of “Ferrous Bicarbonate” iron. Add 3 grains per gallon of hardness for each ppm iron when sizing.
3. These conditioners will not purify or make your water safe to drink.
4. Water pressure must be between 25 and 120 psi.
5. Water temperature must not exceed 110ºF and the unit cannot be subject to freezing conditions.
6. Product improvements and design changes subject to change without notice.
CABINET MODELS
DEMAND CAPACITY SERVICE MINERAL BRINE TIME CLK
MODEL MINERAL LOW SALT MED. SALT HIGH SALT FLOW RATING TANK TANK SIZE DLFC BLFC INJ. MODEL
NAME CU.FT. GRAINS/LBS GRAINS/LBS GRAINS/LBS GPM/PSI (INCHES) (INCHES) (GPM) (GPM) SIZE NAME
WM1-16M 0.50 9,800/3.0 14,100/5.0 16,600/7.5 6.1/6.8 7 x 44 18 x 33 1.2 0.25 0 WM1-16
WM1-24M 0.75 14,700/4.5 21,200/7.5 24,900/11.3 8.4/9.7 8 x 44 18 x 33 1.5 0.50 0 WM1-24
WM1-32M 1.00 19,600/6.0 28,200/10.0 33,200/15.0 10.0/10.7 9 x 48 18 x 33 2.0 0.50 0 WM1-32
WM1-48M 1.50 29,400/9.0 42,300/15.0 49,800/22.5 09.7/10.3 10 x 54 18 x 40 2.4 0.50 1 WM1-48
WM1-64M 2.00 39,200/12.0 56,400/20.0 66,400/30.0 12.0/11.6 13 x 54 18 x 40 3.5 0.50 2 WM1-64
WM1-96M 3.00 58,800/18.0 84,600/30.0 99,600/45.0 12.0/10.6 14 x 65 18 x 40 4.0 1.0 3 WM1-96
DEMAND CAPACITY SERVICE MINERAL CABINET TIME CLK
MODEL MINERAL LOW SALT MED. SALT HIGH SALT FLOW RATING TANK SIZE DLFC BLFC INJ. MODEL
NAME CU.FT. GRAINS/LBS GRAINS/LBS GRAINS/LBS GPM/PSI (INCHES) (WxHxD) (GPM) (GPM) SIZE NAME
WM1-16MC 0.50 9,800/3.0 14,100/5.0 16,600/7.5 6.1/6.8 07 x 35 14x46x22 1.2 0.25 0 WM1-16C
WM1-24MC 0.75 14,700/4.5 21,200/7.5 24,900/11.3 8.4/9.7 08 x 35 14x46x22 1.5 0.50 0 WM1-24C
WM1-32MC 1.00 19,600/6.0 28,200/10.0 33,200/15.0 10.0/10.7 10 x 35 14x46x22 2.0 0.50 0 WM1-32C
MODEL NO. ___________________
