Page 6
Insert the square plug into the socket on the left side of the BL-1000 LINK. Connect the flat
plug to the USB port of the PC.
If both BL-1000 LINK and PC are switched on, the BL-1000 LINK is automatically recognized
after the USB driver is installed.
2.5 Connection via Bluetooth
1. Please make sure that your BL-1000 LINK is connected to the power supply and
switched on.
2. Under "Settings", open the "Bluetooth and other devices" window.
3. Make sure that Bluetooth is turned on.
4. Select the "Add Bluetooth or other device" function.
5. The "Add device" window appears. Now select the "Bluetooth" option.
6. Now Bluetooth devices are searched and all reachable ones are listed. Please be
patient for a moment. Select the BL-1000 LINK and then confirm with the "Connect"
button.
7. The pairing process and the installation of the required drivers will take place. Please
be patient for a moment. After completion, the message "The device has been
successfully added to this computer" appears, which you can close with the "Close"
button.
Now the BL-1000 LINK is wirelessly connected to the PC and you can use all functions as
if an interface cable was connected.
Notice:
If you leave the radio range of the Bluetooth connection (approx. 10 meters) with the BL-
1000 LINK, the connection to the PC is disconnected.
2.6 Technical data
Name: Braille Labeler
Model: BL-1000 LINK
Interfaces: Bluetooth 5.0 (BR/EDR/LE)
USB interface, Ver. 2.0, Type B
Braille Tape: P/N BLTP-13A, length 10m
Power connection: AC adapter
(Input AC 100 - 240V, 50/60Hz, Output DC 15V)
Power: Max 18W
Operation at temperature: 5 to 35 °C
Operation at humidity: 20% to 80% RH (NO DEW)
Dimensions: width 19.8 cm, length 12 cm, height 7.1 cm
Weight: approx. 800 g
2.7 System requirements
Operating system: Windows ® 8/8.1/10 (64/32)
Processor: Intel® Pentium® 1.3 GHz
Memory: 512 MB system memory
Drive: CD-ROM drive
