Helvi PC75 - Page 68

Torch-2
PT 100
ELECTRODE TIP DIFFUSER
OUTSIDE
PROTECTION
NOZZLE
SPACERS
23010077
Cutting
20/70A
23015236B
23015239B 23015240B 23015241B 23015242B
Ø 0,9 mm (30-40 A) Ø 1,0 mm (40-50 A) Ø 1,1 mm (50-60 A) Ø 1,2 mm (60-70 A)
23015237B 23015245B
23015247B
Cutting
80/120A
23015243B 23015244B
Ø 1,4 mm (80-90 A) Ø 1,5 mm (100-110 A)
23015238B 23015246B
Contact
cutting
20/70A
23015251B 23015252B 23015253B
Ø 1,0 mm (40-50 A) Ø 1,1 mm (50-60 A) Ø 1,2 mm (60-70 A)
23015237B
23015256B
23015257B
Contact
cutting
80/120A
23015254B 23015255B
Ø 1,4 mm (80-90 A) Ø 1,5 mm (100-110 A)
23015238B 23015258B
Long
Contact
cutting
30/70A
23015267B
23015268B 23015269B 23015270B
Ø 1,0 mm (40-50 A) Ø 1,1 mm (50-60 A) Ø 1,2 mm (60-70 A)
23015237B 23015273B
Long
Contact
cutting
80/120A
23015271B 23015272B
Ø 1,4 mm (80-90 A) Ø 1,5 mm (100-110 A)
23015238B 23015274B
Gouging
23015236B 23015265B
Gouging 23015238B 23015266B
Ø
Ø
Ø
1
4
m
m
B
Ø
1
0
m
8B
Ø10
23015238B
2
3
0
1
5
2
3
8
B
5
6
B
2301 2 8
23015266
2
3
0
1
5
2
7
3
B
23015274B
ELECTRODE
DIFFUSER
TIP
OUTSIDE
PROTECTION
NOZZLE
SPACERS
