17730-241 13 Parts Lists
VEHICLE
KEY NO. PART NO. DESCRIPTION QTY.
VEHICLE
KEY NO. PART NO. DESCRIPTION QTY.
AR2
™
1 Equalizing Beam Assembly 2
See Selection Guide 45745-147
2 44643-009L Cross Tube 44
7
⁄8", (If converted from RT•RTE 1
suspension, refer to Lit. No. SP-168 Parts List)
Use Center Bushing End Plug 22281-000 for
Cross Tube Replacement
3 Rubber Center Bushing 2
49400-000L 40K Welded End Plug
49600-000L 40K w/Loose End Plug
29483-005L 46K Welded End Plug
34013-097L 46K w/Loose End Plug
4 34013-087L Non-Shim Type, Includes Key No. 7a, 8
5 34013-088L Shim Type, Includes Key Nos. 6a, 7b, 8
34013-188L Rotating Bar Pin (Not Shown), Shim Type,
Includes Key Nos. 6a, 7c, 8
6 Bar Pin Shim 8
a 50130-000 0.19" / 0.19" Standard
b 50131-000 0.25" / 0.12" Optional
c 57026-000 0.375" Optional at shim
7 *Bar Pin End Bushing 4
a Non-Shim Type
b Shim Type
c Rotating Bar Pin, Shim Type (Not Shown)
8 34013-104
Includes Key Nos. 9-11
9 *1"-8 UNC x 6" Hex Bolt 8
10 *1" Hardened Washer 16
11 *1"-8 UNC Locknut 8
12
34013-049L 40K, Includes Key Nos. 13a, 14
34013-073L 46K, Includes Key Nos. 13b, 14
13
a 45000-007L 40K
b 21140-034L 46K
14 45900-000L Rubber End Bushing 4
15 LH Frame Hanger Assembly - Blank 1
65461-001 33.94-34.19" Frame Width
65461-003 34.25-34.50" Frame Width
65461-005 34.56-34.81" Frame Width
RH Frame Hanger Assembly - Blank (Not Shown) 1
65461-002 33.94-34.19" Frame Width
65461-004 34.25-34.50" Frame Width
65461-006 34.56-34.81" Frame Width
16 Trailing Arm Assembly,
Includes Key Nos. 17, 24-27
• Left Hand 1
65655-001 40K - 9½"
65655-003 40K - 10½"
65655-005 46K - 9½"
65655-007 46K - 10½"
• Right Hand 1
65655-002 40K - 9½"
65655-004 40K - 10½"
65655-006 46K - 9½"
65655-008 46K - 10½"
Includes Key Nos. 17-18
34013-111L 40K
34013-112L 46K
17 Trailing Arm Bushing 2
45900-000L 40K
29878-001L 46K
18 21140-053L Adapter Assembly, Includes Key Nos. 19-23 2
19 45289-003 Adapter Tube 2
20 45871-000 Trailing Arm Adapter 4
21 30550-005 1"-14 UNS x 9¾" Bolt 2
22 22962-008 1" Hardened Washer 4
23 08017-000 1"-14 UNS Locknut 2
24 58795-000 Saddle Cap 4
25 06696-000
7
⁄8"-14 UNF Saddle Cap Stud 8
26 22962-002
7
⁄8" Hardened Washer 8
27 04842-000
7
⁄8"-14 UNF Locknut 8
28 Air Spring Assembly
65455-002L Forward 2
65652-002L Rear 2
29 Air Spring Bracket
65426-000 Forward 2
65680-000 Rear 2
49177-017
Includes Key Nos. 30-34
30 22962-001 ¾" Hardened Washer 4
31 17700-031 ¾"-16 UNF Nylocknut 4
32 65999-000 ½"-13 UNC x 2¼" Stud, Replaces 65454-000 8
33 22962-011 ½" Hardened Washer 8
34 17700-010 ½"-13 UNC Nylocknut 8
35 60665-012L Shock Absorber 2
50754-013 Single Upper Shock Bracket and Fastener 2
Service Kit, Includes Key Nos. 36-39
36 67463-001 Shock Bracket, Replaces 65000-001 2
37 50764-010 ¾"-10 UNC x 4¾" Bolt 2
38 22962-001 ¾" Hardened Washer 2
39 49842-000 ¾"-10 UNC Locknut 2
50754-018
Includes Key Nos. 40-42
40 50764-013 ¾"-10 UNC x 7½" Bolt 2
41 22962-001 ¾" Hardened Washer 4
42 49842-000 ¾"-10 UNC Locknut 2
43 65427-000 Lower HCV Bracket 2
57977-000 Height Control Valve Assembly, Includes 2
Key Nos. 44-47
44 60501-000 Height Control Valve 2
45 *¼" Hardened Washer 4
46 *¼"-20 UNC Locknut
47 *Height Control Valve Bracket 1
57430-004
Includes Key Nos. 48-50
48 58035-004
3
⁄8"-16 UNC x 1¼" Bolt 4
49 22962-015
3
⁄8" Hardened Washer 4
50 17700-006
3
⁄8"-16 UNC Nylocknut 4
51 58994-001 Height Control Valve Linkage Assembly 2
Includes Key Nos. 52-58
52 *Linkage Extension Rod 2
53 *Adj. Valve Arm Joint 2
54 *Valve Arm Clamp 2
55 *
5
⁄16"-18 UNC Stud 4
56 *
5
⁄16"-18 UNC Jam Nut 4
57 *
5
⁄16" Hardened Washer 4
58 *
5
⁄16"-18 UNC Locknut 4
59 **One-piece ULTRA ROD
®
PLUS
™
Longitudinal
Torque Rod Assembly Straddle/Straddle,
Specify Length in mm, Includes Key No. 61a
72000-XXX Front 1
72001-XXX Rear 1
60 ***One-piece Transverse Torque Rod Assembly 2
Straddle/Taper, Specify Length in mm
72350-XXX ULTRA ROD PLUS, Includes Key Nos. 61a-62a
92350-XXX XTRB, Includes Key Nos. 61b-62b
61 Straddle Bushing 6
a 64400-002L ULTRA ROD PLUS
b 66649-002L XTRB
62 Taper Bushing 2
a 64400-004L ULTRA ROD PLUS
b 66649-004L XTRB
To Next Page
