Product Description 4 17730-241
AR2
™
1
40K 46K
Suspension Rating 40,000 lbs. 46,000 lbs.
Gross Vehicle Weight (GVW) Approval
2
73,000 lbs. 80,000 lbs.
Gross Combination Weight (GCW) Approval 160,000 lbs. 190,000 lbs.
Site Travel Rating
3
See Below
5
60,000 lbs.
Diagonal Articulation
4
14"
Ride Heights 9.5", 10.5"
Axle Spacing 52", 54"
Lift Axle See Below
5
See Below
6
AR2 is approved for vocational truck applications such as dump under 18 feet, crane / boom and platform
applications. Contact Hendrickson for approval of additional applications.
1. Conversion kit — if existing RT • RTE suspension includes bronze center bushings, they must be replaced
with rubber center bushings. Bronze center bushings are not compatible with transverse torque rods.
Any comparison to other suspensions should consider all of these components, including axle
brackets.
2 Contact Hendrickson for applications that may exceed GVW approval ratings.
3 Site Travel Rating — Ratings are limited to no more than 5% of vehicle operation at speed not to
exceed 5 mph. Site travel ratings are consistent with published axle manufacturer’s limitations. Axle and
suspension site travel specications must not be exceeded.
4 Suspension articulation may exceed vehicle’s capability and may be limited by vehicle manufacturer;
vehicle manufacturer installed axle stops may restrict suspension’s articulation.
5 No add-on lift axles approved for 40,000 lbs. applications.
6 One or more lift axles. Maximum 60,000 lbs. load suspension for site travel.
