Henley Arklow - Technical Specification; Dimensions; Weight and Output

Technical Speciication
www.henleystoves.com | 3
All sizes are correct at time of publish but are subject to change without prior notice. Pleae ensure you confrim all measurements
before commencing any installation works.
All sizes in MM
Safe distances to combustible materials should be 800mm to
the rear and 700mm to the side
Model Size A Size B Size C Size D Size E Size F
Arklow 5kW 591 499 352 388 88 499
Arklow 7kW
591 499
439
481 88
499
Size B
Size A
Size E
Size F
Size C
Size D
Weight 77kg
Nominal heat output, kW 7kW
Arklow 7kW
Weight 70kg
Nominal heat output, kW 5kW
Arklow 5kW
