Air Controls
Henley Stoves appliances have air systems provid-
ing cleaner burning, and greater eiciency and
control, please see the diagram to view where the
various air controls are located on your Henley
Stove.
1) Primary Air - Turning this wheel anti-clockwise
opens the primary air and allows air into the stove.
You would normally open this wheel when start-
ing a ire to allow air into the stove for maximum
combustion.
2) Secondary Air (Airwash)- The secondary air
allows a ilm of air to pass over the glass which in
turn keeps the glass clean. Please note the glass
may become visibily darker when the stove is cold.
3) Tertiary Air - Tertiary air further compliments
the cleanburn system as a third air intake. The air
is drawn up the back of the stove via a series of
chambers and is then injected into the back of the
upper ire chamber through small steel jets. The
jets of superhot air ignite the remainder of gases



Combustible Materials



Make sure that there is a gap between an un-insulated lue system and any combustible material. This gap must be at least 3x the
outside diameter of the lue pipe, or 1.5x the lue diameter to non-combustible surfaces.
8 | www.henleystoves.com
Stove Door
Door Handle
Riddle Bar
Primary Air Intake
Right to open the primary air
Left to close the primary air
