Mobile Rope Measurement MSM 12
Henning GmbH Page 14 2.0 / 3.2009
Figure 8: Suspension ratio setting
7.4.2.4 Set date / time
Under this menu item you can set the internal real time clock of the mobile rope load
meter MSM12. The current time and the date are stored together with each storage
of the measured values, so that later you can recognize when these measurements
have been carried out.
Figure 9: Set date /time
The new time or time and date are entered with the buttons 0 – 9. The digit position
of the time or date which you can currently change is displayed by a flashing digit. By
pressing the OK button the set data is adopted by the real-time clock. If you press
the ESC button, you will leave this menu item without resetting the clock. After press-
ing the OK or ESC button you return to the configuration menu.
