PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Frame 1
2 Nut 3
3 Fixed foot 3
4 Hex socket head cap screw 3
5 Adjustable foot 1
6 Compressed spring 1
7 Foot adjustment post 1
8
Cross-recessed pan
head tapping screw
7
9 Pressure line card 1
10 Switch box 1
11 Eccentric limit block 2
12
Cross recessed pan
head tapping screw
4
13 Reinforcement panel 1
14 Socket head cap screw 2
15 Front panel 1
16 Angle sign 1
17 Spindle 1
18 Hex socket head cap screw 17
19 Lock handle 1
20 Nut 1
21 Lock nut 1
22 Handwheel 1
23 Rotation handle 1
24 Handle screw 1
25 Switch fixing plate 1
26 Angle pointer 1
27 Flat pad 8
28 Cross recessed pan head screw 5
29 Spring pad 1
30 Switch 1
31 Emergency stop switch surface 1
32 Rotation pin 1
33 Switch lock 1
34 Spring pad 16
35 Flat pad 16
36 Left side panel 1
37 Anti-bending jacket 1
38 Power cable 1
39 Ring 2
40 Bevel gear 2
41 Lift 1
42 Lifting lever 1
43 Flat key 2
44 Blade protection plate 1
45 Pressure line card 2
Part Description Qty
46 Hex socket head cap screw 8
47 Spring pad 12
48 Flat pad 12
49 Body 1
50 Lifting lever 1
51 Cross recessed pan head screw 5
52 Cross recessed pan head screw 5
53 Lifting guide column 2
54 Anti-cover plate 1
55
Cross recessed countersunk
head screw
4
56 Gear cover 1
57 Bearing 1
58 Ring 1
59 Output shaft 1
60 Semicircle key 1
61 Gear wheel 1
62 Oil bearing 1
63 Steel ball 8 1
64 Fixed seat spring 1
65 Cylindrical pin 2
66 Front cover 1
67 Handle compression spring 1
68 Hex socket set screw 1
69 Compression set 1
70 Nut 3
71 Protection plate 1
72 Windshield 1
73 Bearing 1
74 Armature 1
75 Bearing 1
76 Damping ring 1
77 Cable 1
78 Nut 2
79 Brush component 2
80 Brush component 2
81 Cross recessed pan head screw 5
82 Cover plate 1
83 Hex socket set screw 2
84 Cross recessed pan head screw 4
85 Case 1
86 Stator 1
87
Cross recessed pan
head tapping screw
2
88 Carrying handle 3
89 Cross recessed pan head screw 5
90 Bearing screw 2
