5
11. Using T-40 torx ratchet
wrench service tool, remove
fasteners from carriage.
13. Cut the pellicle off and
remove foam.
12. Remove the seat
assembly from tilt.
14. Using head screw driver
remove the screws from seat
pan.
To Next Page
