16
Do not operate the motorcycle with the
fuel valve in the “RES” position after
refilling. You may run out of fuel, with
no reserve.
2. Do not overfill the tank. There should be
no fuel in filler neck (4). Fill the tank with
fuel (5).
FUEL TANK
Fuel tank capacity is 12.4 litres (minimum)
including usable reserve supply of 2.2 litres.
1. To unlock fuel tank cap, lift the key hole
cover (1), insert key (2) turn it clockwise
and lift open the cap (3).
(1) Key hole cover (2) Ignition key
2
3. To lock fuel tank cap - close the lid back
on the opening and press gently. The key
springs back to the normal position and
cap gets locked.
4. Remove the key and put back the keyhole
cover.
3
(3) Fuel tank cap
(4) Filler Neck (5) Fuel
Front
5
4
1
