45
If either pad is worn to the bottom of
the grooves replace both pads as a set.
Visit your Authorised Hero MotoCorp
workshop for this service.
(1) Wear Indicator Grooves
Park the motorcycle on its main stand.
Measure the distance brake pedal (1)
moves before the brake starts to take
hold. Free play (2) should be 20-30 mm.
REAR BRAKE
Drum type
3
A
4
(A) CUT-OUT NOT SEATED
(3) Adjusting nut (4) Brake arm pin
3
B
4
(B) CUT-OUT SEATED
