Inspect the sprocket teeth for wear or
damage
Turn the chain to view chain lock plate
(4) inside the hole. Ensure that the chain
lock plate open end (5) is installed in the
opposite direction of the chain rotation.
5
(4) Chain lock plate (5) Open end
Loosen the rear axle nut (1) and sleeve
nut (2).
Adjustment
Turn both the adjusting nuts (4) in an
equal number of turns until the correct
drive chain slack is obtained. Turn the
adjusting nut clockwise to decrease the
slack or anticlockwise to increase the
slack of the chain.
Loosen the drive chain lock nut (3).
Park the motorcycle on its main
stand with the transmission in neutral
and the ignition switch "OFF"
position.
4
(1) Drive chain (2) Hole cap
(3) Drive chain slack
1
