49
Always visit your Authorised HeroMotoCorp
workshop if you see any symptom of battery
discharge as earliest as possible to get the
battery charged. The battery has a tendency to
discharge rapidly if additional electrical
accessories are fitted on the motorcycle.
Battery charging
Battery storage
1. If in case your motorcycle is not used for
more then a month remove the battery, fully
charge and store in a cool and dry place.
6. Pullout the battery from the battery box.
3. Remove the right side cover screws (1)
and remove the side cover (2).
Battery removal
3. Always ensure the battery is fully
charged before installation.
1. Make sure the ignition switch is "O FF"
2. Remove the seat (page 17).
5. Disconnect the negative (-) terminal lead
(5) from the battery first, then disconnect
the positive (+) terminal lead (6).
4. Ensure the battery leads are properly
connected to the battery terminals during
installation.
2. If the battery is expected to be stored for
more then two months, ensure to fully
charge the battery once in a month.
4. Remove the bolt (3) from band battery (4).
Battery installation
2. Check all fasteners are secure.
1. Reinstall in the reverse order of
removal. Be sure to connect the positive
(+) terminal first, then the negative (-)
terminal.
2
1
5
6
34
(1) Right side cover screws (2) Side cover
(3) Bolt (4) Band battery (5) Negative (-)
terminal (6) Positive (+) terminal
