HERO HUNK - Motorcycle Controls and Indicators; Front Top View Controls; Front View Indicators

(12) High beam indicator
(22) Leg guard
(14) LCD (Liquid Crystal Display) panel
(15) Neutral indicator
(19) Headlamp switch
(13) Tachometer
(17) Throttle grip
(16) Front brake lever
(18) Starter switch
(20) Ignition switch with steering lock
(21) Fuel tank cap
(4) Clutch lever
(7) Rear view mirror
(10) Fuel indicator
(6) Choke lever
(8) Reset button
(11) Turn signal indicator
(1) Horn switch
(2) Turn signal switch
(3) Headlamp dimmer switch
(5) Pass lamp switch
(9) Select button
7
1
2
3
FRONT TOP VIEW
5
4
22
19
17
18
16
21
20
6
11
10 13
14
15
12
8 9
*Accessories and features shown may not be part of standard fitment.
