HERO Passion Pro - IGNITION SWITCH; Ignition Switch Operation and Positions

11
“ON”
“OFF”
The engine can be started, Turn
signal lamps, Horn, Tail/Stop lamp and
Passing Switch can be operated. Fuel
Gauge, Odometer and Tripmeter
reading will be functional.
3
1
2
Steering can be locked
“LOCK”
Engine cannot be started and no
electrical system will be functional.
“OFF” Position /
Lock Open
“LOCK” Position
“ON” Position
IGNITION SWITCH
(1) Ignition switch
(2) Ignition key
(3) Steering lock position
