HERO Passion Pro - LUBRICATION AND FRONT BRAKE (DRUM TYPE); Drive Chain Lubrication; Front Brake (Drum Type) Adjustment

42
NOTE
Visit Authorised Hero MotoCorp
workshop for inspection, cleaning,
lubrication and adjustment of drive chain at
every 2000 kms.
FRONT BRAKE (Drum Type)
If adjustment is necessary turn the
adjusting nut (3).
1. Park the motorcycle on its main stand.
2.
3.
Spoke wheel version
4
Turn the engine “OFF”, park the
motorcycle on its main stand and shift
the transmission to neutral.
(1) Front brake lever (2) Free play 10-20 mm
(3) Adjusting nut (4) Brake joint pin
brake joint pin
(2)
SAE # 90 oil.
